HVAC
Practical HVAC design, equipment, controls, energy and refrigerant guidance.


Hydronic Pipe Loss at Low Flow: Recheck Reynolds Number Before Squaring the Flow Ratio
In fully developed laminar flow, halving flow halves straight-pipe pressure loss rather than quartering it. Check fluid properties and flow regime before rescaling a system curve.
Oct 205 min read


Parallel Hydronic Branches: Equal Pressure Drop Does Not Mean Equal Flow
Two branches can experience the same pressure difference while carrying very different flows. A worked network example shows how to calculate the split and avoid adding parallel losses.
Oct 124 min read


AHU Filter Energy: Use the Pressure-Drop History, Not Just the Clean Rating
Two filters can start at the same resistance and impose different energy requirements over a service cycle. Compare the history at matched airflow and filtration duty.
Oct 124 min read


Cooling Energy from Trend Logs: Weight Each Load by Its Time Interval
A cooling load reading needs a duration before it becomes energy. Timestamp spacing and logger semantics determine how each row belongs in the total.
Oct 124 min read


Actual vs Standard Airflow: Reconcile the Mass-Flow Basis Before TAB
Two airflow readings can describe the same air mass while showing different volumes. Declare the reference conditions before diagnosing a balancing discrepancy.
Oct 124 min read


HVAC Energy and Cooling Degree Days: Separate Weather from Performance
A hotter month can consume more energy even when operation improves. Adjust the baseline to the reporting weather before interpreting the difference.
Oct 124 min read


Fan Sound Power vs Room Sound Pressure: Build an Octave-Band Path
A fan’s sound-power rating is only the source. Trace the duct path, add terminal-generated sound and apply a receiver-specific room correction before judging comfort.
Oct 114 min read


Condensate Pump Selection: Duty Flow Is Not Shutoff Head
A maximum-lift label does not establish useful pumping capacity. Calculate the operating flow, then check inflow, cycling, discharge routing and overflow protection.
Oct 114 min read


Hydronic Ultrasonic Flow Sensors: Installation Checks Before Trusting Accuracy
A plausible flow reading can still be biased. Separate meter specification, installation conditions and BMS scaling with a practical hydronic commissioning checklist.
Oct 114 min read


Fan Energy Index: Compare Selections at the Actual Duty Point
FEI changes with the selected operating point. An original two-duty example shows a clear design-point efficiency advantage disappearing when lower-flow operating hours are included.
Oct 114 min read


Direct Evaporative Cooling: Wet-Bulb Effectiveness and Added Moisture
A useful evaporative-cooler review follows both temperature and water vapor. Work through an 80% effectiveness example, then check what a higher wet-bulb temperature does to the available cooling.
Oct 114 min read


Warehouse Loading-Door Infiltration: Separate Cooling Load from Daily Energy
Door-open duration changes daily thermal energy, while the exchange rate during an opening controls instantaneous load. Keep both quantities visible and make the uncertain airflow assumption explicit.
Oct 114 min read
